Espressif ESP32 WROOM32 4M 32Mbit Flash Genuine Quality
Out of stock
1) Xtensa 32-bit LX6 microprocessors
2) 1 Kbit of EFUSE, 256 bits MAC
3) WiFi: 802.11 b/g/n/d/e/i/k/r (802.11n up to 150 Mbps)
4) Bluetooth v4.2 BR/EDR and BLE specification
5) Wi-Fi mode Station/softAP/SoftAP+station/P2P
6) Operating voltate: 2.2-3.6V
₹236.44 (Exc. GST)
Out of stock
Compare-
Microcontroller Boards
Espressif ESP32 WROOM32 4M 32Mbit Flash Genuine Quality
1) Xtensa 32-bit LX6 microprocessors
2) 1 Kbit of EFUSE, 256 bits MAC
3) WiFi: 802.11 b/g/n/d/e/i/k/r (802.11n up to 150 Mbps)
4) Bluetooth v4.2 BR/EDR and BLE specification
5) Wi-Fi mode Station/softAP/SoftAP+station/P2P
6) Operating voltate: 2.2-3.6VSKU: TAF7-006 -
Projects For Sale, USB to TTL Programmers
Universal TTL Auto Programmer
This single programmer will help you to program multiple microcontroller chips/boards. This board got dedicated slots for programming
- ESP32 Cam Board
- ESP32/ESP8266 Chip
- Arduino Pro mini
Along with that, it also got a dedicated pinout of a regular TTL programmer using which you can program almost all the microcontroller chips. This simplifies the programming of the Microcontroller significantly since no manual reset and boot mode selection is needed when using with a common USB to serial interface. It’s a must have tool for all IOT and Electronics Engineers.
SKU: TCF3-003
About ESP32 WROOM32 Module
ESP32 WROOM32 is powerful, generic Wi-Fi+BT+BLE MCU modules that target a wide variety of applications, ranging from low-power sensor networks to the most demanding tasks, such as voice encoding, music streaming, and MP3 decoding.
The ESP32-WROOM-32 MCU Modules use the ESP32-D0WD chip at its core. This SoC features two CPU cores that can be individually controlled, and the CPU clock frequency is adjustable from 80MHz to 240MHz. The ESP32 integrates a rich set of peripherals, ranging from capacitive touch sensors, Hall sensors, SD card interface, Ethernet, high-speed SPI, UART, I2S, and I2C.
If you want to directly get started using ESP32, we will recommend going for ESP32 Development Board rather than this module. That will be much easier and convenient for you.
Specifications
| Processor | Xtensa 32-bit LX6 |
|---|---|
| Operating Voltage (VDC) | 2.2 ~ 3.6 |
| WIFI | 802.11 b/g/n |
| Bluetooth Version | BLE, v4.2 BR/EDR |
| Crystal Oscillator | 40 MHz |
| Wi-Fi Mode | Station/softAP/SoftAP+station/P2P |
| Security | WPA/WPA2/WPA2-Enterprise/WPS |
| Encryption | AES/RSA/ECC/SHA |
| Current Consumption (mA) | 80 |
| Length (mm): | 31.5 |
| Width (mm) | 18 |
| Height (mm) | 3.3 |
| Weight (gm) | 12 |
| Shipping Weight | 0.01 kg |
| Shipping Dimensions | 5 × 4 × 1 cm |
Pinouts
Package Includes:
| Weight | 0.002 kg |
|---|
