In this project you can control 4 AC appliances and Speed of 1 ceiling fan using internet via Blynk and without internet via manual switches and fan regulator. This Same project will also work with other IoT Platforms like, Arduino IoT Cloud, Firebase Realtime database etc. For controlling the speed of the fan we have used capacitive dimming method. And also you can get real time feedback of switches and fan regulator on your IoT Platform.



Connection Diagram:-

Now you have to do connection as shown below

Project Includes:-

Esp32                                         1pcs

Hi-Link HLK 5m05                      1pcs

Two terminal connector           10pcs

5v relay                                      7pcs

Diode 1n4007                            7pcs

Transistor bc5407                      7pcs

Resistor 330 ohms                     7pcs

Slide switch                                1pcs

Male header                               1pcs

Capacitor 2.2uf 250v                 1pcs

Capacitor 3.3uf 250v                 1pcs

Resistor 200k ohms 1/4w         2pcs

Resistor 2.2 ohms 1/4w            2pcs

Resistor 10k ohms                     8pcs

PCB                                             1pcs
