7432 Quad 2-Input OR Gate IC (DIP-14 Package)

7432 Quad 2-Input OR Gate IC (DIP-14)

The 74HC32 is a reliable and versatile quad 2-input OR gate IC designed for a wide range of digital electronics applications. It integrates four independent OR gates into a single compact package, making it a practical choice for logic control, signal processing, and embedded system designs.

Built using high-speed CMOS technology, this IC offers fast switching performance with a typical propagation delay of around 23 ns, while maintaining low power consumption. Its wide operating voltage range from 2V to 6V makes it compatible with both 3.3V and 5V logic systems, giving you flexibility across different projects.

With push-pull outputs, the 74HC32 can efficiently drive digital loads, ensuring stable and clean output signals. The DIP-14 package makes it easy to handle and ideal for breadboards, prototyping, and through-hole PCB designs.

Whether you’re working on educational projects, DIY circuits, or industrial logic applications, the 74HC32 delivers consistent performance even in demanding temperature conditions.

Key Features

• Contains 4 independent 2-input OR gates
• Wide operating voltage: 2.0V to 6.0V
• Fast switching speed: ~23 ns propagation delay
• Low power consumption CMOS design
• Push-pull outputs for strong drive capability
• Output current:
  • High-level: -5.2 mA
  • Low-level: 5.2 mA
• Wide temperature range: -55°C to +125°C
• DIP-14 package – easy for prototyping and soldering

Applications

• Digital logic circuits
• Microcontroller interfacing
• Signal combining and logic control
• Embedded systems
• Educational and DIY electronics projects

Package Includes

• 1 x 74HC32 Quad 2-Input OR Gate IC (DIP-14)
