7404 Hex Inverter NOT Gate IC (DIP-14 Package)

The 7404 Hex Inverter IC is a reliable and widely used logic component designed to perform signal inversion in digital circuits. Inside this compact chip are six independent NOT gates, each capable of flipping an input signal—turning HIGH into LOW and LOW into HIGH. This makes it an essential building block for a variety of logic operations, waveform shaping, and signal processing tasks.

Built using high-speed CMOS technology, the 74HC04 offers efficient performance with low power consumption. It operates comfortably around 5V, making it compatible with most standard digital electronics and microcontroller-based projects. Each gate works independently, giving you flexibility to use multiple inversion stages within a single IC.

The DIP-14 package ensures easy handling and soldering, especially for breadboards and through-hole PCB designs. Whether you’re designing logic circuits, experimenting with digital electronics, or building learning projects, this IC is a practical and dependable choice.

Key Specifications:

• Logic Type: Hex Inverter (NOT Gate)
• Technology: CMOS
• Operating Voltage: 4.75V to 5.25V
• Input Logic High: ≥ 2V
• Input Logic Low: ≤ 0.8V
• Output Current: Up to 16mA
• Number of Gates: 6
• Pin Count: 14
• Package Type: DIP (Through Hole)
• Operating Temperature: 0°C to 70°C

Applications:

• Digital logic circuits
• Signal inversion and buffering
• Oscillators and waveform generation
• Microcontroller interfacing
• Educational and DIY electronics projects

Package Includes:

• 1 x 74HC04 Hex Inverter IC
