Seeed Studio XIAO ESP32C3


Seeed Studio XIAO ESP32C3 featuring ESP32C3 carries a complete Wi-Fi system along with Bluetooth Low Energy function. With its exquisite design, WiFi+BT ability, it’s perfect for various IoT controlling scenarios and complex carriable applications.

550.00 846.61

Compare

Product Details

Seeed Studio XIAO ESP32C3 featuring ESP32C3 carries a complete Wi-Fi system along with Bluetooth Low Energy function. With its exquisite design and WiFi+BT ability, it’s perfect for various IoT controlling scenarios and complex carriable applications.

Features

  • Outstanding RF performance:  Powerful ESP32-C3 SoC and U.FL antenna provided that supports WiFi/Bluetooth connection over 100m.
  • Thumb-size Design: 21 x 17.5mm overall dimension, portable and lightweight.
  • Low power consumption: Lowest as 44 μA (deep sleep mode), with 4 working modes available.
  • Onboard battery charge IC: Supports battery charging, great for various wearable scenarios and wireless IoT applications.
  • Ready for productization:  Single-sided components design, easily integrated into other boards.

Specification

Parameter Description
Processor ESP32-C3 SoC
RISC-V single-core 32-bit chip processor with a four-stage pipeline that operates at up to 160 MHz
Wireless Complete 2.4GHz Wi-Fi subsystem
Bluetooth 5.0/ Bluetooth mesh
On-chip Memory 400KB SRAM & 4MB Flash
Interface 1x UART, 1x IIC, 1x IIS, 1x SPI,11x GPIO(PWM), 4x ADC
1x Reset button, 1x Boot button
Dimensions 21 x 17.5mm
Power Circuit operating voltage: 3.3V@200mA
Charging current: 50mA/100mA
Input voltage (VIN): 5V
Deep Sleep Power Consumption Deep Sleep Model: >44 μA
Wi-Fi Enabled Power Consumption Active Model: <75 mA
Modem-sleep Model: <25 mA
Light-sleep Model: <4 mA
BLE Enabled Power Consumption Modem-sleep Model: <27 mA
Light-sleep Model: <10 mA

Pinouts



Application

  • Internet of Things
  • Wearable devices
  • Health monitoring
  • Education
  • Low-Power(LP) networking
  • Rapid prototyping

Getting Started Video

Documents

XIAO ESP32C3 WiKi

ESP32C3 Datasheet

Weight 0.003 kg
HSN Code

84733010
