Rectangular Speaker – 2W / 8 ohm -70 x 30mm

Add to wishlist
Compare
Specifications:
– Impedance: 4 ohm ± 15%
– Maximum power: 0.25 ~ 3W
– Frequency response: 200 ~ 10000Hz
– Sensitivity: 86 ± 3dB
– Magnet size: Ø44
– Weight: 20g
– Dimensions: 70,70 x 30,70 x 17,50 mm

₹110.17 ₹127.12

Compare

Product Description

30*70 mm YDP3070 3-watt 4-ohm raw metal frame TV speaker micro speaker

General Specs of the speaker :

Impedance 4 ohm
Rated power 3 watt
Max. power 5 watt
SPL sound pressure level 80±3dB at 1m/1w
Fo Lower resonance frequency 550Hz± 20%
Frequency response Fo-8kHz
Material metal frame
Magnet NdFeB
Weight 30.6 g
Dimensions 30.0*70.0*16.0 mm

Applications:

The raw audio speaker used for hifi active or passive line array speakers systems,

Could also be used for multimedia devices, car electronics, smart home appliances, and IoT devices which need to play some sound more than beep ones, like vocal warning messages, or music.



Main advantages:

Profession used for professional hifi active or passive line array speakers systems,

RoHS and REACH COMPLIANT All our speakers are RoHS and REACH conformed, environmentally friendly





Drawing of speaker:
30*70 mm Ydp3070 3 Watt 8 Ohm Raw Metal Frame TV Speaker Micro Speaker

Frequency reponse:

30*70 mm Ydp3070 3 Watt 8 Ohm Raw Metal Frame TV Speaker Micro Speaker
SKU: TAF6-002 Categories: , Tag:
Weight 0.028 kg
HSN Code

85182900
