About 3.5in TFT Touchscreen display
3.5 inch TFT Touchscreen SPI Interface 480×320 TFT Touch Screen Display for Arduino is big (3.5″ diagonal) bright and colorful! 480×320 pixels with individual RGB pixel control, this has way more resolution than a black and white 128×64 display, and double our 2.8″ TFT.
As a bonus, this display has a resistive touchscreen sensor allowing you to control your application simply by touching any area of the screen. This display has a controller built into it with RAM buffering so that almost no work is done by the microcontroller.
Features :
- 3.5-inch color screen,support 65K color display,display rich colors
- 480X320 resolution, optional touch function
- Easy to expand the experiment with SD card slot
- Provide a rich sample program
- Military-grade process standards, long-term stable work
- Provide underlying driver technical support
- Using the SPI serial bus, it only takes a few IOs to illuminate the display
Specifications:
| Name | Parameter |
| Display Color | RGB 65K color |
| Screen Size | 3.5(inch) |
| Type | TFT |
| Driver IC | ILI9488 |
| Resolution | 480*320 (Pixel) |
| Module Interface | 4 Wire SPI Interface |
| Active Area (AA area) | 48.96×73.44(mm) |
| Module PCB Size | 56.34×98(mm) |
| Operating Temperature | -20℃~60℃ |
| Storage Temperature | -30℃~70℃ |
| VCC power voltage | 3.3V~5V |
| Logic IO port voltage | 3.3V(TTL) |
| Rough Weight(Package containing) | With touch: 57 (g) |
Package Includes :
- 1 x 3.5″ Inch TFT Touch Screen Module
- 1 x Stylus
Important Links
- User Manual and Datasheets:
- Library for using this display in Arduino IDE – https://github.com/Bodmer/TFT_eSPI
- Please use this User Setup.h File if you are using this display with ESP32 Board – User_Setup.h
- Please use this UserSetup.h File if you are using this display with ESP32 Cam Board – User_Setup.h
